GMF-28STR (φ1.4~3.2mm)
● 5 axes high speed spring coiler (Feed Roller, O.D., Wedge pitch, Push pich, Cutter)
● Servo control MS mode
● Auto edit program for springs
● Long wire feed at fixed cam position
● TEACH / EDIT
● Repeat function
● TEST function
● Optional spring gauge, torsion tools, etc.
|
Model |
GMF-28STR |
|||||
|
Wire Dia. |
1.4-3.2 mm 0.055-0.126 in |
|||||
|
Max. O.D. |
50 mm 1.968 in |
|||||
|
Display |
Chinese And English |
|||||
|
Max. Production Rate |
200 PCS/MIN |
|||||
|
Motor |
Y Axis 4400W |
C Axis 1800W |
P Axis 1800W |
D Axis 1300W |
P1 Axis 750W |
|
|
Min. Value |
0.01 mm |
0.01° |
0.01° |
0.01° |
0.01° |
|
|
Max. Value |
9999.99mm |
360.00° |
360.00° |
360.00° |
150.00° |
|
|
Weights |
Machine 970 kg 2140 lbs |
Wooden Case 1160 kg 2560 lbs |
||||
|
Dimensions |
Machine 145 × 112 × 161 cm 57 × 44 × 64 in |
Wooden Case 158 × 140 × 188 cm 62 × 55 × 74 in |
||||
|
Power |
3PH 220V 60HZ Customer Specified Available |
|||||
The specifications are subject to change without notice.
