Special mold Heading Machine
●Material-saving
●Low cost molds
●Shorten processing time
●Products with infinitely lengthened possibility
|
Forging Load |
40000 KGS |
|
Max. Wire Diameter |
6~10 |
|
Max. Blank Length |
25~350 mm |
|
Punch Hole |
52 mm |
|
Machine RPM/Output |
15~40 pcs/min |
|
Feeding Mechanism |
Feeding Vibrator (Single Direction, A, B, or C type depends on actual products.) |
|
Auto Feeding Length |
25~200 mm |
|
Main Drive Motor |
25 HP |
|
Machine Dimension(mm) |
4450 x 1780 x 2000 |
|
Machine Weight |
18000 KGS |
The specifications are subject to change without notice.
